Configuring Cisco Umbrella Connectors

Connectors allow Stellar Cyber to collect data from external sources and add it to the data lake.

Stellar Cyber connectors with the Collect function (collectors) may skip collecting some data when the ingestion volume is large, which potentially can lead to data loss. This can happen when the processing capacity of the collector is exceeded.

Connector Overview: Cisco Umbrella

Capabilities

  • Collect: Yes

  • Respond: No

  • Native Alerts Mapped: No

  • Runs on: DP

  • Interval: Configurable

Collected Data

Content Type

Index

Locating Records

Cloud Firewall Logs

DNS Logs

IP Logs

Proxy Logs

 Syslog

msg_class:

ciscoumbrella_cloudfirewalllogs

ciscoumbrella_dnslogs

ciscoumbrella_iplogs

ciscoumbrella_proxylogs

msg_origin.source:

ciscoumbrella

msg_origin.vendor:

ciscoumbrella

msg_origin.category:

dnssec

Domain

N/A

Response Actions

N/A

Third Party Native Alert Integration Details

N/A

Required Credentials

  • Data Path, Access Key, and Secret Key

               Let us know if you find the above overview useful.

Adding a Cisco Umbrella Connector

To add a Cisco Umbrella connector:

  1. Configure Cisco Umbrella log management
  2. Add the connector in Stellar Cyber
  3. Test the connector
  4. Verify ingestion

Configuring Cisco Umbrella Log Management

To configure Cisco Umbrella log management:

Use our example as a guideline, as you might be using a different software version.

  1. Log in to your Cisco Umbrella dashboard at https://umbrella.cisco.com .

  2. Click Admin. The Admin menu expands.

  3. Click Log Management. The Log Management page appears.
  4. In the Amazon S3 section, configure your S3 storage:

    1. If your company has an Amazon S3 bucket, enter the Amazon S3 bucket name and click Verify.

    2. To use Cisco-managed Amazon S3 storage, select a region and retention duration.

  5. Click Save. A confirmation dialog appears.

  6. Click Continue. Your storage is activated, and an activation screen appears. Copy the Access Key and Secret Key to a safe location.

  7. Click Got it!. The Continue button becomes active.

  8. Click Continue. The Amazon S3 section now displays your S3 storage.

  9. Copy the Data Path and add a forward slash (/) to the end of the value.

Adding the Connector in Stellar Cyber

With the data path and keys ready, you can add a Cisco Umbrella connector in Stellar Cyber:

  1. Log in to Stellar Cyber.

  2. Click System | Integration | Connectors. The Connector Overview appears.

  3. Click Create. The General tab of the Add Connector screen appears. The information on this tab cannot be changed after you add the connector.

    The asterisk (*) indicates a required field.

  4. Choose Web Security from the Category drop-down.

  5. Choose Cisco Umbrella from the Type drop-down.

  6. For this connector, the supported Function is Collect, which is enabled already.

  7. Enter a Name.

    This field does not accept multibyte characters.

  8. Choose a Tenant Name. The Interflow records created by this connector include this tenant name.

  9. Choose the device on which to run the connector.

  10. (Optional) When the Function is Collect, you can create Log Filters. For information, see Managing Log Filters.

  11. Click Next. The Configuration tab appears.

    The asterisk (*) indicates a required field.

  12. Enter the Data Path you copied earlier. Make sure there is a forward slash (/) at the end of the value.

  13. Enter the Access Key you copied earlier.

  14. Enter the Secret Key you copied earlier.

  15. Enter the Interval (min). This is how often the logs are collected. By default, the interval is 10 minutes.

  16. Choose the Content Type you would like to collect. The logs for Cloud Firewall Logs, DNS Logs, IP Logs, and Proxy Logs are supported.

  17. Click Next. The final confirmation tab appears.

  18. Click Submit.

    To pull data, a connector must be added to a Data Analyzer profile if it is running on the Data Processor.

The new connector is immediately active.

Testing the Connector

When you add (or edit) a connector, we recommend that you run a test to validate the connectivity parameters you entered. (The test validates only the authentication / connectivity; it does not validate data flow).

For connectors running on a sensor, Stellar Cyber recommends that you allow 30-60 seconds for new or modified configuration details to be propagated to the sensor before performing a test.

  1. Click System | Integrations | Connectors. The Connector Overview appears.

  2. Locate the connector that you added, or modified, or that you want to test.

  3. Click Test at the right side of that row. The test runs immediately.

    Note that you may run only one test at a time.

Stellar Cyber conducts a basic connectivity test for the connector and reports a success or failure result. A successful test indicates that you entered all of the connector information correctly.

To aid troubleshooting your connector, the dialog remains open until you explicitly close it by using the X button. If the test fails, you can select the  button from the same row to review and correct issues.

The connector status is updated every five (5) minutes. A successful test clears the connector status, but if issues persist, the status reverts to failed after a minute.

Repeat the test as needed.

ClosedDisplay sample messages...

Success !

Failure with summary of issue:

Show More example detail:



Verifying Ingestion

To verify ingestion:

  1. Click Investigate | Threat Hunting. The Interflow Search tab appears.
  2. Change the Indices to Syslog. The table immediately updates to show ingested Interflow records.
